16.1 Inch Big Display Business Laptops
Product Detailed Specification
| Product Characteristic | 16 inchs Laptop | |||||
| System Physical Standard Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Main structure | Form Factor | Plastic | ||||
| Dimensions | 357*230*20.5mm | |||||
| Weight | about 1.6KG | |||||
| Color | Silver | |||||
| LCD | Screen Size | 16" | ||||
| Screen Resolution | 1920*1200 ,IPS | |||||
| Touchpad | HID-I2C | TRUE | ||||
| Fan | TRUE | |||||
| Fingerprints | FT9369 | TRUE | ||||
| Battery | Type | Rechargeable Lithium-ion polymer battery 7.7V | ||||
| Capacity | 6000mAh/46.2Wh | |||||
| Working Time | 2.5Hrs(Max. Brightness) | |||||
| System Hardware Configuration: | ||||||
| Type | Details | Descriptions | ||||
| CPU | Type | Intel® Jasper Lake Celeron® Processor N5095/N95/N100 | ||||
| Speed | 2.0GHz-3.4GHZ | |||||
| GPU | Type | Intel® UHD Graphics 450 MHz-750 MHz | ||||
| Memory | Capacity | SODIMM 8GB/16GB（Optional） | ||||
| Camera | Front | 0.3M | ||||
| Rear | / | |||||
| Speaker | Built-in | Stereo Speakers 8Ω/1.0W | ||||
| Micphone | Built-in | Double Analog Microphone | ||||
| Hall switch | Built-in | TRUE | ||||
| Network Connections: | ||||||
| Type | Details | Descriptions | ||||
| WIFI/BT Module | WIFI | CM251 - Support 802.11B/G/N&AC （Optional） | ||||
| Bluetooth version | BT 5.0 | |||||
| Ethernet Network | RJ45 | / | ||||
| Interface Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Storage | SSD | M.2(2280)*1 Support SATA | ||||
| SATA Interface | 2.5inchs SATA Interface*1 | |||||
| SIM Card Slot | Data Storage | / | ||||
| USB Interface | Support Data Transfer | USB3.0*1 & USB2.0*2 | ||||
| TypeC Interface | USB-C | / | ||||
| Headphone Jack | Music Output | ∮ 3.5mm standard headphone jack | ||||
| HDMI Interface | Video Output | Mini HDMI | ||||
| Keyboard | Input Device | Backlit Keyboard | ||||
| DC Interface | Power supply | 12V3A | ||||
| TF Card Slot | Extended external storage | / | ||||
| Main Accessories: | ||||||
| Type | Details | Descriptions | ||||
| Power adapter | Standard Configuration | DC DIAMETER: ∮3.5mm | ||||
| Inputting | 100-240V~1.0A 50/60HZ | |||||
| Output | 12V3A | |||||
| Software Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Operating System | Windows | Windows 10/Windows 11 | ||||
As a custom laptop designed for enterprises, educational institutions and remote workers, the XU-160 redefines the cost-effectiveness of entry-level mobile workstations through its 16-inch 1920×1200 IPS large screen and highly customized architecture. Equipped with an Intel Jasper Lake Celeron N100 processor (4 cores and 4 threads, turbo frequency 3.4GHz) and Intel UHD Graphics core graphics, it can smoothly run multi-tasking office, 4K video playback and lightweight graphics processing, meeting the needs of online meetings, educational courseware production, cross-border e-commerce management and other scenarios.
Analysis of the core advantages of Custom laptop
1. Modular hardware architecture: precise matching based on demand
Flexible performance: supports flexible selection of three CPUs: N5095/N95/N100, memory can be expanded to 16GB DDR4 (46% increase in bandwidth in dual-channel mode)
Storage combination: M.2 SATA SSD (up to 1TB) + 2.5-inch mechanical hard disk (optional 2TB), achieving high-speed system response and large-capacity cold data storage
Network customization: optional 802.11ac WiFi 5 module (867Mbps rate) or 4G LTE expansion kit to ensure connection stability for outdoor operations
2. 16-inch productivity screen: revolutionary upgrade of visual efficiency
Screen technology: 16:10 golden ratio IPS screen, the visible area is 11% higher than the traditional 15.6-inch, and the 178° wide viewing angle covers 100% sRGB color gamut
Scene adaptation:
Finance personnel: 40 rows of Excel tables can be displayed on a single screen, and data verification efficiency is increased by 30%
Educational institutions: Split-screen display of courseware + online resource library, enhanced teaching interactivity
Remote team: Mini HDMI external dual screens to build a three-screen office environment
3. Enterprise-level security and durable design
Biometrics: FT9369 fingerprint sensor (0.3 seconds to unlock) + Windows Hello double verification
Strong structure:
1.6kg lightweight body passed the 1.2-meter drop test, and the hinge durability reached 25,000 opening and closing times
Splash-proof backlit keyboard (optional) + dual-microphone beamforming technology, voice recognition accuracy increased by 65% in noisy environments
Technical architecture innovation
Intelligent cooling system: turbo fan + copper tube thermal conductivity design, 45℃ environment continuous load CPU temperature ≤72℃
Battery life optimization solution:
46.2Wh battery supports PD fast charging (charged to 50% in 30 minutes)
Dynamic refresh rate adjustment (60Hz/40Hz automatic switching), video conferencing battery life extended to 4.5 hours
Expanded interface ecology:
USB3.0*1+USB2.0*2 direct connection to printers/scanners and other office peripherals
Reserved M.2 2230 slot for expandable WiFi 6E or Bluetooth 5.2 module
Scenario-based solution
Cross-border e-commerce operation
Multi-store management system (supports 10 browser tabs in parallel)
Time zone intelligent switching function, adapted to global customers online communication
Smart classroom terminal
ClassIn teaching software pre-installed, touchpad supports gesture annotation
Battery hot-swappable design (optional dual battery module), all-day uninterrupted teaching
Logistics field workstation
4G module realizes real-time synchronization of orders in remote areas
DC 12V power supply compatible with car cigarette lighter, seamless connection of mobile office
OEM/ODM customization service
Appearance customization: support corporate LOGO laser engraving, Pantone color card shell customization and anti-glare matte screen options
System pre-installed: Windows 11 Pro multi-language version/Ubuntu LTS/customized Linux distribution
Batch deployment: BIOS-level hardware whitelist management, adapted to enterprise IT control strategy
As a flexible solution in the field of Custom laptop, XU-160 has become an ideal tool for digital transformation of small and medium-sized enterprises, education informatization upgrade and cross-border freelancers through the free combination of hardware configuration and batch procurement cost advantages. We are now open to in-depth customized cooperation, providing three-year global warranty and exclusive supply chain support to help customers build differentiated competitiveness.
